EMS AirFlow S1 User Manual

7
Technical data
Description of the unit
The powder unit of the AirFlow
®
S1 is primarily intented for remov-
ing soft deposits and discolourations from all visible areas of teeth
as well as from ssures and interdental spaces.
The AirFlow
®
S1 is driven by a pneumatic footswitch.
7
Technical data
Description of the unit
The powder unit of the AirFlow
®
S1 is primarily intented for removing
soft deposits and discolourations from all visible areas of teeth as well
as from ssures and interdental spaces.
The AirFlow
®
S1 is driven by a pneumatic footswitch.
Description of the electrical parts
Manufacturer: EMS SA - 1260 Nyon, Switzerland
Models: AirFlow
®
S1
Classication: EN 60601-1 Class I
Type B
IP 20
93/42 CEE: Class IIa
Mode of operation: Continuous operation
Supply voltage: 100 V AC / 110 V AC
220 V AC
240 V AC
Main frequency: 50 - 60 Hz
Power consumption: max. 75 VA / for CSA units 115 VA*
Fuses Primary: ø 5 x 20 mm, 250 V
for 100V AC/110V AC, T 1 A, time-lag
for 220V AC/240V AC, T 0.5 A, time-lag
Secondary: ø 5 x 20 mm, 250 V, T 2.5A, time-lag
Compressed air supply: 4.5 to 7 bar (450 to 700 kPa) >15 Nl/min
(66 to 102 Psi)
Water supply: Cold water 1 to 5 bar (100 to 500 kPa)
(15 - 73 Psi)
Operating conditions: +10
o
C to +40
o
C (+50F to 104F)
30% to 75% relative humidity
Storage and transport
conditions: -10
o
C to +40
o
C (+14F to 104F)
10% to 95% relative humidity
Air pressure: 500 hPa to 1060 hPa
Weight: Approx. 3.6 kg (8.1 lbs)
Dimensions: Height: 120 mm
Width: 250 mm
Length: 250 mm
* For units sold in the USA and Canada
