Installation
Caution:
The DAG 9.2X2 card software must be installed before the card itself is
physically installed into the computer.
DAG software package
The latest DAG Software package must be installed before you install the DAG 9.2X2 card itself. For
details on installing the latest DAG Software package, refer to the following:
•
EDM04-01 DAG Software Installation Guide
•
EDM04-37 Windows DAG Software Installation Guide
PCIe Gen 2.0 Slot
The DAG 9.2X2 card operates on an 8 lane PCIe Gen 2.0 bus and can be installed in any free 8 lane PCIe
Gen 2.0 slot.
The PCIe Gen 2.0 bus architecture allows multiple DAG cards to be installed without affecting the
bandwidth used by each DAG 9.2X2 card.
