Endace DAG 9.2X2 - Time_Mode; Txonly; Txrxerror;Notxrxerror; Tx_Crc;Notx_Crc

EDM01-36v10 DAG_9.2X2_Card_User_Guide - Configuring the DAG card
32 ©2010 - 2012 Endace Technology Ltd. Confidential - Version 10 - May 2012
time_mode
Applicable to TR-TERF.
Sets the time release mode.
nodelay sends packets out with no delay. Shows as no_time_mode.
relative mode sends out packets in the same time spacing as they were received.
See also relative (page 30), nodelay (page 29
).
Example
dagconfig nodelay
dagconfig relative
tx_crc/notx_crc
Modes: Ethernet, WAN only.
Enables the crc(fcs) in the transmitted packets CRC(FCS).
Example
dagconfig tx_crc
dagconfig notx_crc
txonly
Configures the memory hole to transmit only.
Example
dagconfig txonly
Notes:
• Only displayed if the DAG card supports transmit (i.e. has a TERF image).
• This option is only applicable on firmware images containing TX.
txrxerror/notxrxerror
Indicates how to process packets that are transmitted with an RX error flag. Packets are either
discarded
(notxrxerror) on or transmitted (txrxerror).
Note:
Only displayed if the DAG card supports transmit (i.e. has a terf image).
Example
dagconfig txrxerror
dagconfig notxrxerror
wan
Set the DAG card into WAN receive mode.
Example
dagconfig wan
Version information
Details the following information about the connected DAG card:
• Firmware image programmed in the FPGA.
• The DAG card serial number.
• The MAC address(s) of the DAG card's ports (Ethernet cards only).
