4-pin to RJ45 adapter
A 4-pin (plug) to RJ45 (socket) adapter is supplied with your DAG card. This adapter allows you to plug a
standard Ethernet RJ45 PPS signal cable into your DAG card. The 4-pin to RJ45 adaptor pin assignments
are shown below:
RJ45 socket Signal name 4 Pin plug
1
PPS Out+
2
2
PPS Out-
1
3
PPS In+
4
6
PPS In-
3
