Ender 2 Pro - Assembly Guide: Securing XZ-axis Kit; Fastening XZ-axis Components

5. Fix XZ-axis Kit 固定XZ轴组件
9
M4x16 hexagon socket x 2
button head screws
M4x16内六角平圆头螺丝
10
10
M5 x 45 cylinder-head
combination screw
with washer
x 2
M5×45圆柱头带垫组合螺丝
9
A.Screw up two M4x16 hexagonal socket button head cap screws from the front. | 将两颗M4x16内六角平圆头螺丝从正面扭紧固定。
B.Tighten and secure it with two M5x45 cylinder-head combination screws with washer from the bottom. | 再用两颗M5x45圆柱头带垫组合螺
丝从底部扭紧固定。
05
