Ender 2 Pro - Assembly Guide: Installing the Material Rack; Attaching the Spool Holder

Fix the threaded end of the material tube on the rack, then align the screw hole of the rack with the position of the base, and finally fix it
with one M5x40 hexagonal socket button head cap screw. (As shown in the figure)
将料管带螺纹的一端固定在料架上，再把料架的螺孔对准底座组件的位置，最后用一颗M5x40内六角平圆头螺丝扭紧固定。（如图所示 ）
11
11
M5x40 hexagon
socket button head
screws
x 1
M5x40内六角平圆头螺丝
6
6
Rack
I
料架 x 1
7
7
Spool
I
料管 x 1
6.Install the Rack 安装料架组件
06
