Ender 2 Pro - Connecting Printer Cables; Motor and Limit Switch Wiring

A.Connect X, E, Z-axis motor wires according to the yellow label on the 6-pin (5 wires) port. | 按照6-pin（5根线）端口上黄色标签提示连接X、E、Z
轴步进电机。
B.Connect X, Z-axis limit switch wires according to the yellow label on the 3-pin (2wires) port. | 按照3-pin（2根线）端口上黄色标签提示连接X、Z轴
限位开关。
X、Z-axis limit switch
X、Z轴限位开关
X、E、Z -axis motor port
X、E、Z轴电机接口
4
8. Cable Connection 设备接线
E
X
X
Z
Z
08
