32
24. 24. Isolation Cover Isolation Cover
Included with the Water Quality System is an Isolation Cover designed to protect the equipment from water intrusion.
This cover MUST be installed. Failure to install the Isolation Cover voids the warranty.
Position the Isolation Cover (A) over the Heater-Controller Mounting Board (B). The tabs of the cover nest into the slots at
the top of the mounting board. Use the provided 1/2” (13mm) screws (C) to attach the cover (Fig. 53).
B
Fig. 53
25. 25. Pool Equipment Start Up Pool Equipment Start Up
The pool is full when the water level completely covers the honeycomb grill (Fig. 54) where the current is produced. A
water level 1/2” (13mm) or more below the top of the grill can cause air to get pulled through the skimmer-filter and into
the plumbing lines. This can lead to problems with the filter, and can also cause your heater to work intermittently. A
water level 1” (25mm) or more above the top of the grill can lead to water getting splashed out of the pool.
Once the pool is full and all connections are made, the Water Quality System can be started. Make sure ALL ball valves
in the plumbing are open (red handle parallel with plumbing).
Fig. 54
