Heater-Controller Plug-In Connections
e Heater-Controller (In.xe) features in.links connectors with
colored and tagged polarizers. is plug and connector technolo-
gy has been specically designed for easy and safe assembly. e
tags are interchangeable depending on the output; the polarizers
are designed to avoid misconnections. Fig. 92.
Fig. 92
Fig. 93
Propulsion
System Pump
Unused
Connection
Circulating Pump
Unused
Connection
Unused
Connection
Keypad Connection
Unused Connection
Unused Connection
In.link connectors are easily and conveniently accessible from the front of the Heater-Controller oering a wide range of possible
connection congurations. In.link connectors come in 3 sizes (HC, LC, and low voltage) for all types of inputs and output devices.
ey all include an integrated latch that keeps them safely in place and provides audible and tactile feedback when properly connected.
Finally, colored and tagged polarizers provide a denite advantage in easily conguring output devices. Refer to Fig. 93 for conguring
your equipment.
