Operation Deltabar S FOUNDATION Fieldbus
18 Endress+Hauser
5.3.2 Selecting an option
Example: Selecting the "Pressure" measuring mode.
5.3.3 Editing a value
Example: adjusting DAMPING VALUE function from 2.0 s to 30.0 s. ä 16, Section 5.2.3
"Function of the operating elements – onsite display connected".
Onsite display Operation
P01-xxxxxxxx-19-xx-xx-en-017
"Flow" has been selected as the measuring mode. A ✓ in
front of the menu text indicates the active option.
P01-xxxxxxxx-19-xx-xx-en-033
Use "+" or "–" to select "Pressure" as the operating mode.
P01-xxxxxxxx-19-xx-xx-en-034
1. Confirm your choice with "E". A ✓ in front of the
menu text indicates the active option.(The "Pressure"
measuring mode is selected.)
2. Jump to the next item with "E".
Onsite display Operation
P01-xxxxxxxx-19-xx-xx-en-023
The onsite display shows the parameter to be changed. The
value highlighted in black can be changed. The "s" unit is
fixed and cannot be changed.
