Deltabar S FOUNDATION Fieldbus Commissioning
Endress+Hauser 37
6.5.4 Quick Setup menu for the Level measuring mode
!
Note!
• Some parameters are only displayed if other parameters are appropriately configured. For
example, the EMPTY CALIB. parameter is only displayed in the following cases:
– LEVEL SELECTION "Level Easy Pressure" and CALIBRATION MODE "Wet"
– LEVEL SELECTION "Level Standard", LEVEL MODE "Linear" and CALIBRATION MODE
"Wet"
You can find the LEVEL MODE and the CALIBRATION MODE parameters in the BASIC
SETTINGS function group.
• The following parameters are set to the following values in the factory:
– LEVEL SELECTION: Level Easy Pressure
– CALIBRATION MODE: Wet
– OUTPUT UNIT or LIN. MEASURAND: %
– EMPTY CALIB.: 0.0
– FULL CALIB.: 100.0
• The quick setup is suitable for simple and quick commissioning. If you wish to make more
complex settings, e.g. change the unit from "%" to "m", you will have to calibrate using the
BASIC SETTINGS group. See Operating Instructions BA00303P.
P01-xMD7xxxx-19-xx-xx-xx-079
Fig. 14: Quick Setup menu for the "Level" measuring mode"
1)2)1)
1)
2)
1)
2)
2)
3)
3)
EMPTY CALIB.
FULL CALIB.
LEVELSELECTION
1) On-site display only
2) FieldCare only
3) – LEVELSELECTION "Level Easy Pressure"
and CALIBRATION MODE "Wet"
– LEVELSELECTION = "Level Standard",
LEVEL MODE = "Linear" and
CALIBRATION MODE = "Wet"
PROFILE VIEW
POS. ZERO ADJUST
DAMPING VALUE
MEASURED VALUE
QUICK SETUP
MEASURING MODE
GROUPSELECTION
MEASURING MODEMEASURING MODELANGUAGE
FlowPressure Level
LEVELSELECTION
OPERATING MENU
