Commissioning Deltabar S FOUNDATION Fieldbus
38 Endress+Hauser
!
Note!
For onsite operation, see also Page 16, Section 5.2.3 "Function of the operating elements –
onsite display connected" and Page 17, Section 5.3 "Onsite operation via onsite display".
Onsite operation FieldCare
Measured value display
Switch from the measured value display to GROUP
SELECTION with F.
Measured value display
Select QUICK SETUP menu.
GROUP SELECTION
Select MEASURING MODE.
Measuring Mode
Select the Primary Value Type parameter.
MEASURING MODE
Select "Level" option.
Primary Value Type
Select "Level" option.
LEVEL SELECTION
Select level mode. For an overview see Page 35.
LEVEL SELECTION / Level Selection
Select level mode. For an overview see Page 35.
GROUP SELECTION
Select QUICK SETUP menu.
POS. ZERO ADJUST
Due to orientation of the device, there may be a shift in the
measured value. You correct the MEASURED VALUE via the
POS. ZERO ADJUST parameter with the "Confirm" option, i.
e. you assign the value 0.0 to the pressure present.
POS. ZERO ADJUST
Due to orientation of the device, there may be a shift in the
measured value. You correct the MEASURED VALUE via the
POS. ZERO ADJUST parameter with the "Confirm" option, i.
e. you assign the value 0.0 to the pressure present.
EMPTY CALIB.
1)
Enter level for the lower calibration point.
For this parameter, enter a level value which is assigned to
the pressure present at the device.
EMPTY CALIB.
1
Enter level for the lower calibration point.
For this parameter, enter a level value which is assigned to
the pressure present at the device.
FULL CALIB.
1
Enter level for the upper calibration point.
For this parameter, enter a level value which is assigned to
the pressure present at the device.
FULL CALIB.
1
Enter level for the upper calibration point.
For this parameter, enter a level value which is assigned to
the pressure present at the device.
DAMPING TIME
Enter damping time (time constant ). The damping affects
the speed at which all subsequent elements, such as the
onsite display, measured value and OUT value of the Analog
Input Block react to a change in the pressure.
DAMPING TIME
Enter damping time (time constant ). The damping affects
the speed at which all subsequent elements, such as the
onsite display, measured value and OUT value of the Analog
Input Block react to a change in the pressure.
1) – LEVEL SELECTION "Level Easy Pressure" and CALIBRATION MODE "Wet"
– LEVEL SELECTION "Level Standard", LEVEL MODE "Linear" and CALIBRATION MODE "Wet"
