Brief overview
For quick and easy commissioning:
Brief Operating Instructions
Your new unit has the Operating Instructions built-in. The unit's simple control system enables you
to commission for many applications, practically without any paper. Your unit displays instructions
at the push of a button directly on screen. This description is nevertheless delivered with the unit -
it is a supplement to the Operating Instructions built into the unit. Anything that is not described
directly at the unit by plain text or menus is explained here.
Fig. 1: Variable softkey (e.g. calling up internal Help function in the Setup menu)
Index
A very extensive index can be found at the end of these Operating Instructions. It acts as a
complement to the table of contents and helps you find special terms and functions.
1. Consider the safety instructions Page 5
2. Install the unit Page 8
3. Wire up the unit Page 11
4. Install the provided PC software Page 22
5. Connect the unit with the PC Page 22
6. Set up the unit (via provided PC software) Page 27
7. Transmit the set up files to the unit Page 27
