Endress+Hauser Ecograph T RSG30 User Manual

Wiring
15
4.2.2 Supply voltage
4.2.3 Analog inputs
The first digit (x) of the three-digit terminal number corresponds to the associated channel (1.. to
6..: channels 1 to 6):
Power supply type Terminal
100-230 VAC L+ N- GND
Phase L Zero conductor N Ground
24 V AC/DC L+ N- GND
Phase L or + Zero conductor N or - Ground
Type Terminal
x11 x12 x13 x14 x15 x16
Current (+) (-)
Voltage > 1 V (+) (-)
Voltage  1 V (+) (-)
Resistance
thermometer
RTD (2-wire)
(A) (B)
Resistance
thermometer
RTD (3-wire)
(A) b (sense) (B)
Resistance
thermometer
RTD (4-wire)
(A) a (sense) b (sense) (B)
Thermocouples
TC
(+) (-)
L+ N- PE
CH x
x11
x12
x13
x14
x15
x16
