Commissioning
26
6 Commissioning
6.1 Function check
Make sure that all post-connection checks have been carried out before you put your unit into
operation:
• See Section 3.5 'Post-installation check'
• Checklist in Section 4.4 'Post-connection check'
6.2 Switching on the unit
Once the operating voltage is applied, the display lights up and the unit is ready for operation.
• When you first commission the unit, program the set up in accordance with the description in the
Operating Instructions.
• If you are commissioning a unit that is already configured, measuring is immediately started in
accordance with the settings. The values of the display group currently configured appear on the
display.
6.2.1 Setting the operating language
The default setting for the operating language is English (GB). A different operating language can be
configured in the set up (see Section 6.4.1).
F
-> Set up ->Basic settings -> Language
Fig. 17: Change the operating language
6.3 Unit Set up
6.3.1 General
Access to the set up is released when the unit leaves the factory and can be locked in various ways,
e.g. entering a 4-digit release code ( Chap. 6.4.1 "Basic settings").
When locked, basic settings can be checked but not changed.
You can also put your unit into service and/or configure it via PC. The following are available for
this:
1. CompactFlash card slot for reading in parameters saved on CompactFlash card.
2. Rear RS232/RS485/Ethernet system interface
3. Front-panel USB system port
Advantages of configuration via PC
• The unit data is saved in a database and can be accessed again at any time.
• Text entries can be carried out more quickly and efficiently by keyboard.
