Commissioning
60
Fig. 53: Main menu, "Diagnostic/unit information"
"Diagnostic/unit
information" menu items
Description
Unit information Display of important unit and memory information, such as program name and software version. In addition, the
memory time available is also displayed.
This time is reduced if
• Limit values/events are saved or monitored
• Signal analyses are activated
• Digital inputs are active
Fig. 54: Diagnostic/unit information, "Unit information"
Calibration Calibration must only be carried out by skilled and trained personnel.
"
Caution!
Malfunctions possible if not performed correctly!
Normal trending is interrupted for the complete time that this function is operational. This is also identified in the event
list.
!
Note!
Protection via a service code to prevent unintentional release.
Protocols Boot log: Only for service purposes
Error log: Only for service purposes
!
Note!
Protection via a service code to prevent unintentional release.
Delete internal memory
"
Caution!
Completely deletes the measured values with all analyses recorded in the internal memory. The total counter remains.
!
Note!
The CompactFlash card is not deleted. When the release code (password) is set in the unit, then you will need to enter it.
