Technical data
80
Internal memory:
• Program memory: 2 MB Flash (nonvolatile)
• Setup data memory, measured data memory: permanent back-up of setup data and measured data
in internal Flash memory (nonvolatile)
• Main memory: 2 MB SRAM
Data buffering and RTC buffering with lithium cell (replace after 10 years)
External memory:
• Cyclic copying of the measured data for archiving on CompactFlash card
(CompactFlash base: type I)
• Supported CF memory cards : 32 MB, 64 MB, 128 MB, 256 MB and 512 MB. Please use the CF
memory cards recommended by the manufacturer (see "Accessories").
• A green LED beside the CF slot indicates data access. During this process, the CF card must not
be removed. Risk of losing data!
Typical recording lengths:
Requirements for the following tables:
• No alarm point violation/event storage
• Digital input not used
• Signal analysis deactivated
!
Note!
Frequent entries in the events list reduce the memory availability!
Internal memory (weeks = w, days = d, hours = h):
CompactFlash 128 MB (weeks = w, days = d, hours = h):
CompactFlash 256 MB (weeks = w, days = d, hours = h):
Analog inputs Save cycle 5
min.
Save cycle 1
min.
Save cycle 30 s. Save cycle 10 s. Save cycle 1 s.
1 68 w, 5 d, 0 h 15 w, 1 d, 23 h 7 w, 4 d, 11 h 2 w, 3 d, 19 h 1 d, 18 h
3 34 w, 2 d, 12 h 7 w, 1 d, 20 h 3 w, 4 d, 10 h 1 w, 1 d, 11 h 20 h
6 19 w, 4 d, 10 h 4 w, 0 d, 11 h 2 w, 0 d, 5 h 4 d, 17 h 11 h
Analog inputs Save cycle 5
min.
Save cycle 1
min.
Save cycle 30 s. Save cycle 10 s. Save cycle 1 s.
1 5738 w, 6 d, 14 h 1276 w, 4 d, 7 h 638 w, 2 d, 3 h 212 w, 5 d, 9 h 21 w, 1 d, 22 h
3 2869 w, 4 d, 2 h 606 w, 4 d, 10 h 303 w, 2 d, 5 h 101 w, 0 d, 17 h 10 w, 0 d, 18 h
6 1639 w, 6 d, 0 h 339 w, 4 d, 18 h 169 w, 5 d, 21 h 56 w, 4 d, 7 h 5 w, 4 d, 15 h
Analog inputs Save cycle 5
min.
Save cycle 1
min.
Save cycle 30 s. Save cycle 10 s. Save cycle 1 s.
1 11526 w 3 d, 0 h 2564 w, 0 d, 5 h 1282 w, 0 d, 2 h 427 w, 2 d, 8 h 42 w, 5 d, 3 h
3 5763 w, 3 d, 2 h 1218 w, 2 d, 20 h 609 w, 1 d, 10 h 203 w, 0 d, 11 h 20 w, 2 d, 3 h
