Prothermo NMT81 Operation
Endress+Hauser 73
The items of Measured values
Check the items below and confirm that temperatures, levels and the other items show
appropriate values.
• 72: Liquid temperature
• 73: Vapor temperature
• 74: Product temperature
• 75: Water temperature
• 76: Water level
• 77: Tank level
• Test resistance
• Terminal current
• Terminal voltage 1
• Water bottom frequency ratio
(76)
n
(73)
(74)
(75)
(72)
3
2
1
(77)
A0044825
 69 Measured values
