Modbus Integrator's Guide for the Cordex® CXC HP Controller | 3 - Using Modbus
Table 3-30 AMPS HP modular inverter system data points (continued)
Name Register Format
System Mode 04:Input Register 32-bit Floating Point
• Line = 1
• Inverter = 2
• AC Input Power Limit = 3
• Bypass = 4
• Manual = 5
• Unlicensed = 6
Phase 1 Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 2 Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 3 Output Power (VA) 04:Input Register 32-bit Floating Point
Phase 1 Output Power (W) 04:Input Register 32-bit Floating Point
Phase 2 Output Power (W) 04:Input Register 32-bit Floating Point
Phase 3 Output Power (W) 04:Input Register 32-bit Floating Point
AC Output Voltage 04:Input Register 32-bit Floating Point
DC Input Current 04:Input Register 32-bit Floating Point
DC Input Voltage 04:Input Register 32-bit Floating Point
DC Input Power 04:Input Register 32-bit Floating Point
System On Bypass 04:Input Register 32-bit Floating Point
AC Input Power (VA) 04:Input Register 32-bit Floating Point
# Communicating Inverters 04:Input Register 32-bit Floating Point
# Failed Inverters 04:Input Register 32-bit Floating Point
# Replace Fan Inverters 04:Input Register 32-bit Floating Point
# Comms Lost Inverters 04:Input Register 32-bit Floating Point
# Comms Lost T2S 04:Input Register 32-bit Floating Point
# T2S Not Accepting Commands 04:Input Register 32-bit Floating Point
# T2S 04:Input Register 32-bit Floating Point
Number Of Phases 04:Input Register 32-bit Floating Point
Number Of DC Input Groups
(Feeds)
04:Input Register 32-bit Floating Point
Supported by All T2S 04:Input Register 32-bit Floating Point
