0922001-J0 Rev A
10
User GuideCordex® CXPS-E105 Edge Power Systems
2.3 System configurations
The following configurations are currently available for Cordex® CXPS-E105 edge power systems.
Table A — Cordex® CXPS-E105 edge power system configurations
Rack size Current rating Rectifier
capacity
Load
breakers
Battery
breakers
Shunt LVBD Height
19-/23-inch 187.5 A max. 3 x 2.4 kW 10 2 250 A 225 A 2RU
3 x 3.0 kW
23-inch 200 A max. 4 x 2.4 kW 10 2 250 A 225 A 2RU
4 x 3.0 kW
• Cordex® CXDM-E1 high density 1U 225 A DC distribution panel
• Cordex® CXCi HP system controller
• Cordex® HP 2.4/3.0 kW rectifier shelf
• Top and bottom rear Kydex covers
• User switchable 19-inch rack mount bracket for flush or center mount
• 19-inch to 23-inch rack mount adapters
• IEC C20 receptacles
2.3.1 Three module position shelf with Cordex® CXCi HP controller and IEC input
connectors (PN: 0922001-001)
• Cordex® CXDM-E1 high density 1U 225 A DC distribution panel
• Cordex® CXCi HP system controller
• Cordex® HP 2.4/3.0 kW rectifier shelf
• Top and bottom rear Kydex covers
• User switchable 19-inch rack mount bracket for flush or center mount
• 19-inch to 23-inch rack mount adapters
2.3.2 Three module position shelf with Cordex® CXCi HP controller and TB input
connectors (PN: 0922001-002)
• Cordex® CXDM-E1 high density 1U 225 A DC distribution panel
• Cordex® CXCi HP system controller
• Cordex® HP 2.4/3.0 kW rectifier shelf
• Top and bottom rear Kydex covers
• User switchable 23-inch rack mount bracket for flush or center mount
2.3.3 Four module position shelf with Cordex® CXCi HP controller and TB input
connectors (PN: 0922001-003)
NOTICE
Rectifier modules, DC distribution breakers, temperature sensors, and AC input cables are not
included in the basic configuration.
