User GuideCordex® CXPS-E105 Edge Power Systems
3. Specifications
3.1 Cordex® CXPS-E105 225 A edge power systems
Table B — Cordex® CXPS-E-105 225 A edge power system specifications
Electrical
Input specifications
Cordex
®
HP 3.0 kW rectifier systems Cordex
®
HP 2.4 kW rectifier systems
Input voltage 208 to 277 Vac (nominal)
208 to 250 Vac (nominal) IEC option
90 to 187 Vac (derated)
Input frequency 45 to 66 Hz
Input current (per module) 15.5 A max. (nominal)
14.2 A max. (derated)
System AC requirements 19-inch systems: 3 × 20 A feeds
23-inch systems: 1 × 40 A feeds or 2 × 20 A feeds
Power factor >98% (50 to 100% load) >99% (50 to 100% load)
Output specifications
Output voltage –48 Vdc (nominal)
–42 to –58 Vdc (range)
Output power 19-inch systems: 9,000 W max.
23-inch systems: 10,800 W max. or 9,600 W max. continuous to load
Output current 19-inch systems: 187.5 A max.
23-inch systems: 225 A max. or 200 A max. continuous to load
Characteristics
Cordex
®
HP 3.0 kW rectifier systems Cordex
®
HP 2.4 kW rectifier systems
Eciency >96.5% 96.2%
Acoustic noise <55 dBa
Measured at 1m (3 ft.) and 30°C (86°F)
<60 dBa
Measured at 1m (3 ft.) and 30°C (86°F)
Static load regulation <±0.5% <±0.7%
Dynamic load regulation
(40 to 90%, 90 to 40%)
≤±3.0% for any load change within rated limits
Static line regulation <±0.1%
Temperature stability ≤100 ppm/°C (55.6 ppm/°F) over operating temperature
Time stability ≤0.2% per year
Electrical noise (nominal voltages)
Cordex
®
HP 3.0 kW rectifier systems Cordex
®
HP 2.4 kW rectifier systems
Voice band <53 dBrnC <38 dBrnC
Wide band 10 kHz to
10 MHz
<260 mVrms <20 mVrms
Wide band 10 kHz to
100 MHz
<180 mVpk-pk <150 mVpk-pk
Psophometric <2 mV RMS
