130922001-J0 Rev A
Cordex® CXPS-E105 Edge Power Systems
User Guide
Features
Rectifiers Cordex® HP 3.0 kW rectifier (option)
Cordex® HP 2.4 kW rectifier (option)
Controller Cordex® CXCi HP system controller
Distribution • 10 × plug-in load breaker positions
• 2 × battery breaker positions
• 225 A low voltage disconnect
• 250 A battery shunt
Adjustments • Output voltage
• High voltage alarm
• Low voltage alarm
• High voltage shutdown
• Start delay timer
Protection • Current limit/short circuit
• Startup delay
• Input/output fuses
• Output high voltage shutdown
• Power limiting
• Over-temperature
LEDs
Module Steady green: AC input OK (module)
Steady green: DC output OK (module)
Steady red: Module fail (module)
Distribution Steady green: Power OK (distribution)
Steady yellow: LVD inhibit (distribution)
Steady red: Breaker alarm (distribution)
Mechanical
Mounting Flush or center mount
Dimensions (H × W × D) 19-inch systems: 133 x 482 x 476 mm (3.5 x 19 x 18.75 in.)
23-inch systems: 133 x 584 x 476 mm (3.5 x 23 x 18.75 in.)
Hot positions 12 × sets of 1/4 inch studs on 5⁄8 inch centers
Return positions 13 × sets of 1/4 inch studs on 5⁄8 inch centers
Weight (system) 19-inch systems: 18.3 kg (40.4 lb)
23-inch systems: 19.5 kg (43.1 lb)
Weight (rectifier) 1.83 kg (4.04 lb)
Access Front access after installation
Environmental
Temperature¹ Operation: –40 to 30°C (–40 to 86°F) 200 A max.
–40 to 40°C (–40 to 104°F) 160 A max.
Storage: –40 to 85°C (–40 to 185°F)
Relative humidity 0 to 95% non-condensing
Elevation Up to 2,800 m (9,186 ft)
Cooling Fan-cooled (front to rear)
Heat dissipation 19-inch systems: 514 Watts (1,755 BTU/h) worst case
23-inch systems: 684 Watts (2,334 BTU/h) worst case
¹ Operation temperature range is for applications without active cooling.
