OF
SHEET
OUTLINE DRAWING, CXPS-E105,
19"/23",CX48-2.4/3.0KW,CXCI-HP
0922001-06
31
19.0
17.1
18.26 (19" RACK)
0
0.24
1.49
1.99
3.24
3.47
3.92
RECTIFIERS ARE SHOWN
FOR REFERENCE ONLY.
NOT INCLUDED IN THE SYSTEM
CXDM-E1 MODULAR BREAKER
DISTRIBUTION ASSEMBLY
CORDEX 48V-2.4/3.0kW 19" RECTIFIER SHELF
w/ CXCI-HP SYSTEM CONTROLLER
20.3
18.9
SHOWN WITH REAR COVER INSTALLED
FRONT MOUNTING SHOWN
19.0 (19" RACK)
17.1
23.0
18.26
22.26 (23" RACK)
0
0.24
1.49
1.99
3.24
3.92
3.47
RECTIFIERS ARE SHOWN
FOR REFERENCE ONLY.
NOT INCLUDED IN THE SYSTEM
CXDM-E1 MODULAR BREAKER
DISTRIBUTION ASSEMBLY
CORDEX 48V-2.4/3.0kW 19" RECTIFIER SHELF
w/ CXCI-HP SYSTEM CONTROLLER
MID MOUNTING w/ 19" - 23" ADAPTER SHOWN
6.0
MID MOUNTING
20.3
18.9
19"-23" MOUNTING
ADAPTER BRACKET
w/ 6" OFFSET
SHOWN WITH REAR COVER INSTALLED
0922001-001
