Physical Interface (EAP1250)
Dimensions and Weights
Diameter:132.4mm(5.22”)
Height:37.4mm(1.47”)
Weight:220g(0.49lbs.)
1 Reset Button: Press and hold for over 10 seconds to reset to
factory default settings.
2 LAN Port (PoE): EthernetportforRJ-45cable.
3 Power Connector: 12V DC IN for Power.
4 Ceiling (Wall) Mount Hole: Using the provided hardware, the
EAP AP can be attached to a ceiling or wall.
3
4
1
2
