2021-0306-2507 27 00-02-1207
Shutdown and Warning
This selection will establish the following settings for Analog Inputs 1-4:
Setpoint (numeric value), Rule (Greater than Setpoint, Less
than Setpoint), Action Delay (numeric value in mS).
Note: Warning is disabled when the warning Setpoint =0.
When the defined Rule condition is true, and Action Delay
time outs, a popup message will show.
Setpoint (numeric value), Rule (Greater than Setpoint, Less
than Setpoint), Action Delay (numeric value in mS)
Note: Shutdown is disabled when the warning Setpoint =0.
When the defined Rule condition is true, and Action Delay
time outs, the display will disable the ECU enabled output.
Alt excite fail warning
This selection provides the charging fail warning if enabled. There are two different charging
fail triggering conditions:
• If a digital output function is set to “Alt exciter” function is used in digital out, the output
will try to excite the alternator, and a charginge fail warning will be triggered if voltage
does not increase after 5 attempts.
• If Alternator Potential (SPN 167) or Electrical Potential (SPN 168) CAN messages are
availablepresent, a chargineg fail warning will be triggered after 1 minute if voltage does
not increase.
This selection will establish the following settings for Analog Inputs 1-4:
Warnings: Setpoint (numeric value), Rule (Greater than Setpoint, Less than Setpoint),
Action Delay (numeric value in mS)., and
• Warning is disabled when the warning Setpoint =0. When the
defined Rule condition is true, and Action Delay time outst, a popup message will show.
Formatted: Font: Bold
Formatted: Font: Bold
Formatted: Space After: 12 pt
Commented [NY5]: @Osayamen Imade the alt excite
warning has been moved into the warning and shutdown
and listed after the analogues warning. Please review this
and the analog warning above, so they are looks in the
same sub group.
Formatted: Body Text
Formatted: Indent: Left: 1.27 cm, No bullets or numbering
