Enovation Controls Murphy PowerView PV485 User Manual

2021-0306-2507 36 00-02-1207
1
Select Throttle Settings, then Throttle Method from the Main Menu. Press
Button 5 to select and enter.
2
Use Button 2 or 4 to highlight either Display button or Digital Input.
3
Press Button 3 to confirm and Button 1 to exit the Menu.
Max and Idle RPM
These options allowThis allows the operator to set you to set a limit on thethe limit for max
and idle RPMs needed for idling and maximum powerspeedengine speed.
Step
Action
1
Select Throttle Settings, then Max RPM or Idle RPM from the Main Menu.
Press Button 5 to select and enter.
2
Use Button 2 or 4 to adjust the RPM number.
3
Press Button 3 to confirm and Button 1 to exit the Menu.
Target RPM Type
This option allows the operator you tto select how your RPMs will be displayed as RPM or
Percentage. if percentage is selected the display will calculate the target RPM between the idle
and maximum speed based on 0 to 100%. .
Throttle Method
This setting determines how the increase or decrease of RPMs will be accomplished.
Switch throttle decrease/increase input
Operator can select which input for switch throttle input. The selected input will be used as
digital input. When the input is active engine will continue step towards to the Max/Idle RPM.
Knob throttle input
Operator can select which input for Knob throttle input. The selected input will be used as
resistive input. The default resistance range is set to 0 to 1000ohm, the range can be modified
in the I/O settings. When engine started if the knob position not at home (minimum) position, a
popup up messages will show to asked operator to return the knob to home position.
