SQ-80
Musician's Manual
SELECTING SOUNDS
Master Banks
Each of the three Master Banks,
(INTERNAL, CART A and CART B)
designates a large area of memory which
contains forty Programs. To play the
Programs in the Internal Memory. press
the
INTERNAL Button.
Internal Memory
The SQ-80 holds 40 different Sounds, or "patches" in its Internal Memory. We refer to these Sounds
as Programs. Programs can be selected using the Master Bank Button labeled INTERNAL, the fou
Bank Select Buttons, and the ten Buttons located directly above and below the Display. The Internal
Memory retains its data even when the power is Off.
Cartridge Memory
Before you can select the other two Master Banks. CART A and CART B. an ENSONIQ EPROM
Storage Cartridge (or any other SQ-80- or ESQ-compatible Program cartridge) must be inserted in the
Cartridge slot. The procedures for playing, editing and saving Cartridge sounds are identical to those
for Internal sounds. When a Cartridge has been inserted, all three Master Banks are instantly available.
The E
=
PROM Cartridge also retains its data when the power is Off, whether or not it is plugged into the
SQ-80 Cartridge slot. When there is no Cartridge in the slot, pressing CART A or CART B
ill have
no effect.
Bank Select Buttons
The four Bank Select Buttons, located to the
right of the Master Bank Buttons, and la-
beled 1 through 4, are used to call up the
Programs in Memory, ten at a time, allowin
you to then select the one you want to play.
Press Bank Select Button #1. and the Displa
shows you the names of the ten Programs in
Bank 1. This is the Program Select Page fo
Bank 1. Press Bank Select Button #2, and the
Display shows you the names of the ten Pro-
grams in Bank 2. And so on.
Section 1
First Thin
s Firs
7
