TS-12 Musician’s Manual Section 7 — Effect Parameters
31
FINE Range: -99 to +99
Lets you to fine tune the pitch of Voice-1.
LEVEL Range: 00 to 99
Allows you to adjust the level of Voice-1. A setting of 00 would eliminate any audible pitch shift.
PAN Range: -99 to +99
Allows you to assign the location of Voice-1 in the stereo field. A value of -99 would be far left,
and +99 would be far right.
VOICE-2 SEMI LEVEL
FINE PAN
These parameters are identical to the VOICE-1 parameters, and allow you to define a second
voice for independent pitch shifting.
PITCH SHIFTER - QUALITY Range: LONG/SMOOTH or SHORT/COARSE
Allows you to choose between a long/smooth setting, or a short/coarse setting. A smooth
setting would sound best with slower sustaining chords, whereas a coarse setting would enhance
a rapidly played musical passage. Depending on your sound source and musical needs, set this
parameter accordingly. This parameter actually controls the effect transport delay; smooth yields
a long transport delay, coarse yields a short transport delay.
LFO - RATE Range: 00 to 99
Controls the rate of pitch modulation that creates a chorusing effect. To achieve chorusing, this
rate must be very low.
WIDTH Range: 00 to 99
Controls the excursion of pitch modulation. Since the rate is usually very low, then the width is
usually very large.
Note: When KBD is selected as a MOD SRC, and VOICE-1 SEMI or VOICE-2 SEMI is selected as the
DEST (destination), the pitch will increase one semitone at a time above middle C (C4), and
decrease one semitone at a time below middle C (Middle C being zero). After each octave, the
pitch shift will “wrap” and start again (the pitch can’t be modulated more than one octave in
either direction).
58 FAST PITCH SHIFTER
FAST PITCH SHIFTER has a transport delay of only 10 msec and a maximum detune ratio of one
semitone. Try shifting the voices slightly in both positive and negative values to create a fat
sound. This algorithm should be used for pitch correction (for instance, try using the mod wheel
as a pitch controller). The FX-1 and FX-2 parameters can be routed into the effect with different
Dry/Wet mixes. Depending on its usage, this algorithm generally sounds best with a Mix of dry
and wet. Try using the mod wheel with the Effect Mix parameter(s) to bring in or fade out the
pitch shifted signal(s).
VC-1 FINE Range: -99 to +99
Allows you to fine tune the pitch of Voice-1.
LEVEL Range: 00 to 99
Allows you to adjust the volume of Voice-1. A setting of 00 would eliminate any audible pitch
shift.
