RAK111_ENG / © Ensto 2019
16. Extension Box EVK...
The EVK... is designed as an extension box for EVB100 and EVB200. As default the extension
box is provided with RCB/MCB (combined residual current protection device and a circuit
breaker) and a MID class energy meter.
Note! Cable glands are not included in the delivery.
Please order suitable cable glands separately according to the used cable sizes, for example
Ensto KTM... cable gland series (polyamide or brass).
300 132
400
M12x1,5
Ø20.5 2pcs (Knock-outs)
Ø32.5 2pcs (Knock-outs)
Ø12.5 (Knock-out)
Ø9.5 4pcs
