ensto Wallbox - Technical Information - EVK

34
RAK111_ENG / © Ensto 2019
16.3. Technical Information - EVK...
Electrical Connections and Components
Nominal supply voltage 1-ph/3-ph, 230/400VAC, 50Hz
Supply connections and
terminals
L1, L2, L3, N, PE
Cu 2.5–50 mm²
Tightening torque: 4 Nm (2.5 - 4 mm²), 12 Nm (6 - 50 mm²)
RCB / MCB Type A 30mA, class C, nominal current 32A
Energy measurement MID class energy meter
Design and Mechanics
Materials Polycarbonate
Color Frame: grey RAL7035
Cover: transparent
Dimensions 300 x 400 x 132 mm
Weight approx. 4,1 kg, depends on product conguration
Enclosure class IP66
Shock protection rate IK08
Operating temperature -25 °C … +65 °C
Mounting On wall with fastening lugs
