Connecting to the Network
3-30 Hardware Installation
Figure 3-19 Cable Connection to LC Fiber-Optic Connectors
3. Plugtheotherendofthecableintotheappropriateportontheotherdevice.Some
cablesmaybeterminatedattheotherendwithtwoseparateconnectors,oneforeach
fiberopticstrand.Inthiscase,ensurethat thetransmitfiberopticstrandisconnected
tothereceiveport
andthereceivefiberopticstrandtothetransmitport.
4. VerifythatalinkexistsbycheckingthattheportLink/ActivityLEDison(blinking
greenorsolidgreen).IftheLink/ActivityLEDisoff,performthefollowingstepsuntil
itison:
a. Verifythatthedeviceattheotherendof
thesegmentisONandconnectedtothe
segment.
b. Ifthereareseparatefiberopticconnectionsontheotherdevice,checkthe
crossoverofthecables. Swapthe cableconnectionsifnecessary.
c. CheckthatthefiberopticconnectionmeetsthedBlossandcablespecifications
outlinedintheCablingGuidefor
multimodemodecabling.Toobtainthis
document,refertoRelatedDocumentsonpage xvi.
d. Ifalinkhasnotbeenestablished,refertoChapter 4forLEDtroubleshooting
details.Ifaproblempersists,refertorefertoGettingHelponpage 18for
detailsoncontactingEnterasys Networksforsupport.
5. Repeatsteps
1through4,above,untilallconnectionshavebeenmade.
1 Mini-GBIC MT-RJ port connector 3 Release tab
2 LC cable connector 4 Link/Activity LED
21
22
23
24
21
22
23
24
B2G124-24
À
Â
Á
Ã
