EOS Cubo / Cubo Avantgarde - Installation and Operating Instructions EN-27
Installation
3 Remove the design cover.
a) Loosen the 2 screws at the bottom edge of the design cover.
b) Slide the design cover down slightly and remove it.
4 Unscrew the screws (B) on the terminal box and remove the cover (A).
A Terminal box cover B Screws
A
B
