Epson AL-M200 Series User Manual

Status Monitor (Windows Only)
You can check the printer status with Status Monitor. Double-click the Status Monitor printer icon on
the taskbar at the bottom right of the screen. The Printer Selection window appears, which displays
the printer name, printer connection port, printer status, and model name. Check the column Status
to know the current status of your printer.
Settings button: Displays the Settings window and allows you to modify the Status Monitor settings.
Click the name of the desired printer listed on the Printer Selection window. The Printer Status
window appears.
The Printer Status window alerts you when there is a warning or when an error occurs, for example,
when a paper jam occurs or toner is running low.
By default, the Printer Status window appears automatically when an error occurs. You can specify
the conditions for starting the Printer Status window in Printer Status Window Properties.
To change the pop-up settings for the Printer Status window:
1. Right-click the Status Monitor printer icon on the taskbar at the bottom right of the screen.
2. Select Printer Status Window Properties.
The Printer Status Window Properties window appears.
3. Select the type of the pop-up and then click OK.
You can also check the toner level of your printer and the job information on the Printer Status
window.
Status Monitor is installed along with print drivers.
Launcher (Windows Only)
Using the Launcher-Btype window, you can open the Status Window and Printer Setting
Utility.
To use the Launcher, select to install the Launcher when you install print drivers.
AL-M200 Series User’s Guide
Printer Management Software 23

Epson AL-M200 Series Specifications

General

Print Technology	Laser
Max Resolution	1200 x 1200 dpi
Monthly Duty Cycle	20, 000 pages
Warm-up time	15 seconds
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Paper Input	250-sheet
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Duplex Printing	Yes (Automatic)
