78
Connecting to External Equipment
Connecting to an External Monitor (EB-X6/S6 only)
Computer images being input the Computer Input port can be displayed
on an external monitor and the screen at the same time when connected to
the projector. This means that you can check projected images on an
external monitor when giving presentations even if you cannot see the
screen.
Connect to an external monitor using the cable supplied with the monitor.
q
• Component video signals and images from equipment
connected to the Video port and S-Video port cannot be
output to an external monitor.
• The setting gauge for Keystone, the configuration and
help screen, and so on are not output to an external
monitor.
To monitor port
To Monitor Out port
Cable supplied with
the monitor
To Next Page
