79
Connecting and Removing a USB Device (EB-W6 only)
You can connect a digital camera, hard disk drive and USB memory
compatible with USB 2.0 or 1.1. You can project image files from a
connected digital camera or USB storage device in Slideshow.
s p.90
Connecting a USB Device
This section explains how to connect USB devices using the digital
camera as an example.
Connect with a specified USB cable or one supplied with the digital
camera.
Reading the Indicators
The USB indicator colors are lit as follows to indicate the status of the
USB device connected to the projector.
Removing a USB Device
After finishing projecting, use the following procedure to remove USB
devices from the projector.
A
Turn off power for the digital camera or USB device.
B
Remove from the projector's USB port (Type A).
q
Use a USB cable of up to 3 meters in length. If the cable
length is over 3 meters, the slideshow may not operate
normally.
USB cable
To USB port
(Type A)
To digital camera's
USB port
Attention
• Normal operation is not possible when using a USB hub. Connect
the projector directly to a digital camera or USB storage device.
• When connecting a USB compatible hard disk drive, be sure to
use the hard disk drive's accessory AC adaptor.
: Lit : Off
Indicators Status
(orange) A USB device is connected.
(green) A Slideshow of images from the connected device is
being played.
A USB device is not connected.
Procedure
To Next Page
