Appendix
101
This product is also designed for IT power distribution system with phase-to-phase voltage 230V.
Обладнання відповідає вимогам Технічного регламенту обмеження використання деяких небезпечних
речовин в електричному та електронному обладнанні.
Angle of tilt
If you use the projector tilted at an angle of more than 4°, it could be dam‐
aged or cause an accident.
ESC/VP21 Commands
Use of ESC/VP21 enables control of the projector from an external device. For more details, see the following
Web site.
http://www.epson.com
RS-232C Cable layouts
•
Connector shape: D-sub 9-pin (male)
•
Projector input port name: RS-232C
•
Signal name:
Signal Name Function
GND Signal wire ground
TD Transmit data
RD Receive data
<At the projector> <At the computer>
<At the projector> (PC serial cable) <At the computer>
•
Communications protocol
Default baud rate setting: 9600 bps
Data length: 8 bit
Parity: None
Stop-bit: 1 bit
Flow control: None
