Basic Operations
27
Adjusting the Projected Screen
Displaying the Test Pattern
When adjusting the zoom/focus or the projection position just after setting up the projector, you can display
a test pattern instead of connecting video equipment.
Press the
button on the remote control to display the test pattern.
You can adjust the display position and so on by using this test pattern.
For EH-TW9200W/EH-TW9200, you can also select patterns that display R (red), G (green), and B (blue)
individually, as well as the pattern for adjusting the display position. You can use it as a pattern to perform
color adjustment when an image signal is being input.
Press the
button to end the test pattern display.
For EH-TW9200W/EH-TW9200, you can also end by selecting Exit.
Adjusting the Focus
Turn the focus ring to adjust the focus.
