Epson LabelWorks LW-600P User Manual

4. Select the curve and transformation options you want to use.
You see a preview of your text art in the window.
5. Click the Decoration tab.
6. Select any Fill, Border, and Reverse settings you want to use.
7. Click OK.
You see the outline of your text art block.
8. Drag the block where you want the text art to appear, then click the block to display it on your label.
Parent topic: Designing Labels With Label Editor
Related tasks
Working With Blocks in Label Editor
Editing Layout in Label Editor
You can rearrange and adjust the layout of the blocks of text and other elements on your labels.
1. To edit the layout of a block, click the Edit block icon, and click the block on the Label Editor main
screen.
Note: To select more than one block, press and hold the Shift key on your computer keyboard while
you click the blocks (or choose Select All from the Edit menu).
You see green handles around the selected block.
2. Open the Layout menu.
45

Epson LabelWorks LW-600P Specifications

General

Color	No
Print technology	Thermal transfer
Vertical printing	Yes
Maximum resolution	180 x 180 DPI
Built-in barcodes	Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, GS1-128, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Sustainability certificates	ENERGY STAR
Product color	Black, Grey
Connectivity technology	Wired & Wireless
Pallet width	800 mm
Pallet height	710 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	210 pc(s)
Minimum order quantity	5 pc(s)
Quantity per pallet (UK)	280 pc(s)
Quantity per pallet layer	25 pc(s)
Quantity per pallet layer (UK)	40 pc(s)
Package depth	263 mm
Package width	202 mm
Package height	85 mm
Package weight	1269 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	132 mm
Width	54 mm
Height	146 mm
Weight	440 g
