Commands Arranged by Topic
ESC D
Set Horizontal Tabs
Format:
ASCII code:
ESC D n1 n2 ... 0
Decimal:
27 68 n1 n2 ... 0
Hexadecimal: 1B 44 n1 n2 ... 00
Comments:
This command allows setting of up to 32 horizontal tabs, which
are entered as n1, n2, n3, etc., (from 1 to 255) with the number 0
character terminating the command. The tab settings must be
entered in ascending order. ESC D 0 clears all tabs. The default
settings, when power is turned on or after an ESC @ command,
are at every eight characters. The tab settings are not affected by
changes in cpi. The tab positions in proportional printing are
determined by the 10 cpi character size.
Overall Printing Style
ESC x
Select Letter Quality or Draft
Format:
ASCII code:
ESC
x n
Decimal:
27
120 n
Hexadecimal: 1B 78 n
Comments:
The following values can be used for n:
0: Selects draft mode.
1: Selects Letter Quality (LQ) mode.
Overrides the SelecType panel setting.
9-22
Command Summary
