LS20 Rev.4 v
Before Reading This Manual
This section describes what you should know before reading this manual.
Structure of Control System
The LS20 series Manipulators can be used with the following combinations of Controllers
and software.
Robot Controller RC90 with the following label attached.
Label
RC90 EPSON RC+ 7.0 Ver.7.1.4 or later
Turning ON/OFF Controller
When you see the instruction “Turn ON/OFF the Controller” in this manual, be sure to
turn ON/OFF all the hardware components. For the Controller composition, refer to the
table above.
Shape of Motors
The shape of the motors used for the Manipulator that you are using may be different from
the shape of the motors described in this manual because of the specifications.
Setting by Using Software
This manual contains setting procedures by using software. They are marked with the
following icon.
Figures in this Manual
The figures of manipulators indicated in this manual are basically Standard-model
Manipulator. Unless special instruction is provided, the specifications of Standard-model
and Cleanroom-model are the same.
Photos and Illustrations Used in This Manual
The appearance of some parts may differ from those on an actual product depending on
when it was shipped or the specifications. The procedures themselves, however, are
accurate.
