4. Setting of End Effectors
4.1 Attaching an End Effector
Users are responsible for making their own end effector(s). Before attaching an end
effector, observe these guidelines.
CAUTION
■
If you use an end effector equipped with a gripper or chuck, connect wires and/or
pneumatic
tubes properly so that the gripper does not release the work piece
power to the robot system is turned OFF. Improper connection of the
/or pneumatic tubes may damage the robot system and/or work piece
as the work piece is released when the Emergency Stop switch is pressed.
outputs are configured at the factory so that they are automatically shut off (0)
by power disconnection, the
Emergency Stop switch, or the safety features of the
an end effector to the lower end of the shaft.
For the shaft dimensions,
and the overall dimensions of the Manipulator, refer to
move the upper limit mechanical stop on the lower side of the shaft.
Otherwise, when
is performed, the upper limit mechanical stop may hit
the Manipulator, and the r
obot system may not function properly.
Use a split muff coupling with an
M4 bolt or larger to attach the end effector to the
shaft.
Brake release switch : LS3
up/down by hand because
the
brake is applied to the joint while power
to the robot system
This prevents the shaft fr
hitting peripheral
equipment in the case that the shaft is lowered
weight of the end effector when the
disconnected during operation,
or when the motor is
turned OFF even though the
To move Joint #3 up/down while attaching an end
effector
, turn ON the Controller and press the brake
The shaft may be lowered by
the weight of the end effector.
switch is a momentary-type; the brake is released only while the button
shaft while the brake release switch is being pressed because
the shaft
may be lowered by the weight of the end effector
