Welcome 15
Projector Dimensions
Use the dimensions below to guide you in placing or installing the
projector.
79 mm
77 mm
295 mm
92 mm
39.8 mm;
center of lens
to mounting
bracket holes
93 mm
228 mm
243.5 mm
13 mm
38.3 mm
128 mm
37.5 mm
25 mm
Mounting
screw holes
PowerLite S10+
