Information regarding consumables, such as ink cartridges, are displayed using the following icons and bar
lengths.
Ink cartridge status
Displays the approximate level of remaining ink and the current status. If the amount of ink runs low, the
bar becomes shorter.
The code at the bottom of the bar display indicates the ink color. The bar at the bottom indicates the front
ink cartridge, while the bar at the top indicates the back ink cartridge.
HDK : High Density Black
C:Cyan
M:Magenta
Y:Yellow
The display changes, as shown below, if a warning or error occurs.
The amount of ink is estimated to be low. Once the ink cartridge is expended, the printer
automatically switches to the other ink cartridge.
Confirm that a new ink cartridge is installed on the other side.
Ink is expended. Replace the old ink cartridge with a new one.
More than 30 minutes has elapsed since the ink cartridge connector was disconnected.
Immediately connect the connector, if it is left the way it is, the ink will dry out and the printer may
not function normally.
It is time to shake the ink cartridges. Remove the ink cartridges and shake them.
An ink cartridge's connector is disconnected. Insert the ink cartridge and connect the connector
correctly.
Waste Ink Bottle status
Displays the approximate amount of space available in the Waste Ink Bottle. If the amount of space
decreases, the bar becomes shorter.
The display changes, as shown below, if a warning occurs.
The Waste Ink Bottle is almost full. Ready a new Waste Ink Bottle.
Wiper Roll status
Displays the guideline for replacement of the wiper roll. As the time for replacement gets closer, the bar
becomes shorter.
The display changes, as shown below, if a warning occurs.
SC-F10000 Series User's Guide
