Appendix
149
Printer Specifications
Basic Specifications
Printing method On-demand ink jet
Nozzle configuration 368 nozzles for each color x 2 rows
Print direction Bidirectional printing
Highest resolution 1440 x 1440 dpi
Paper feed method Friction feed
Interface Universal Serial Bus Specifications Revision 2.0
Electrical specifications
Rated voltage AC 100 to 120V AC 220 to 240V
Rated frequency range 50 to 60 Hz 50 to 60 Hz
Rated current 12 A 6 A
Power consumption Approx. 500 W Approx. 500 W
Paper Feeder Specifications
Paper core size Rear roll paper feeder (3 inch core): One roll at a time with an outer diameter 7.87 inches (200
mm) max.
Front roll paper feeder (3 inch core): One roll at a time with an outer diameter 7.87 inches (200
mm) max.
Paper size Rear roll paper feeder: 4 to 6 inches x 328 ft (102 to 152 mm x 100 m) max length, 8 to 12 inches
x 328 ft (203 to 305 mm x 100 m) max length
Front roll paper feeder: 4 to 6 inches x 328 ft (102 to 152 mm x 100 m) max length, 12 inches x 328
ft (203 mm x 100 m) max length
Paper Width 4 inches (102 mm), 5 inches (127 mm), 6 inches (152 mm), 8 inches (203 mm), 10 inches (254 mm),
12 inches (305 mm)
Tip:
O Only the Dual Roll Model supports front roll paper. For the Single Roll Model, information is not displayed under the
front paper item. See the information for rear roll paper.
Safety and Approvals
Safety UL 60950-1
CAN/CSA No. 60950-1
Low Voltage Directive 2006/95/EC EN 60950-1
