4.2.4.6.1 Disassembling the ASF
1. Remove the ASF assembl
y
.
(
Refer to Section 4.2.4.6.
)
2. Remove the brake lever, releasin
g
one arm of the torsion sprin
g
41.2 from the hook of the ASF frame. See Fi
g
ure 4-16.
3. Remove the shaft fixin
g
clip from the ri
g
ht side of the ASF drive
shaft. To release the clip, insert a small flathead screwdriver into
one of the slots next to the lockin
g
tab on its side. Then
g
entl
y
pr
y
the lockin
g
tab up and pull the clip loose from the ASF drive shaft.
4. Remove the ri
g
ht hopper release cam.
5. Graspin
g
the blue paper
g
uide, move the left ASF roller to the center
of the ASF.
6. Remove the white plastic spacer clipped around the drive shaft next
to the left hopper release cam.
7. Push the drive shaft to the left and remove the opto-interrupter
wheel after releasin
g
the hook that holds it in place on the shaft.
8. Disen
g
a
g
e the hopper assembl
y
from the 2 pins on which it pivots
(
left and ri
g
ht
)
at the top of the ASF frame.
9. Move the drive shaft all the wa
y
left, until it comes out of the hole in
the ri
g
ht side of the ASF frame.
(
This should free the ri
g
ht roller
assembl
y
, which
y
ou should now be able to wi
gg
le around.
)
Lift the
ri
g
ht roller assembl
y
so that the drive shaft is
j
ust visible over the top
of the frame, and then free the shaft from the left side of the ASF b
y
slidin
g
it out to the ri
g
ht. Remove the shaft.
(
Durin
g
reassembl
y
, the compression sprin
g
on the ri
g
ht ASF roller
should be compressed to enable the hopper latch
(
see Fi
g
ure 4-16
)
to pass throu
g
h the hole in the ASF frame.
)
10. Remove the left hopper release cam.
11. Remove the hopper assembl
y
to
g
ether with the left and ri
g
ht ASF
rollers.
CAUTION
During disassembly and assembly of the ASF, do not let
grease on the cams touch any other parts. Wipe off any
grease smeared on other parts.
CHECK
POINT
 The hopper release cams and the ASF rollers are
keyed to prevent you from installing them on the drive
shaft in the wrong direction.
 Test the shaft fixing clip and opto-interrupter wheel to
make sure they’re installed securely and don’t slip off.
 Note that the black roller assembly goes on the right
side and the lighter-colored one goes on the left.
