Epson Stylus Color 440 Service Manual

EPSON Stylus COLOR 440, 640, and 740 Chapter 4 Disassembly and Assembly
107
Figure 4-16. Disassembling the ASF
H opper Assem bly
ASF Fram e
Right
H opper R elease C am
ASF Roller Assem bly
Left
H opper R elease C am
Torsion Spring 41.2
Brake Lever
ASF Drive Shaft
Shaft Fixing C lip
H opper Latch
(B la c k )
(W h ite )
O p to -In te rru p te r
Wheel
