Epson Stylus Color 440

EPSON Stylus COLOR 440, 640, and 740 Chapter 4 Disassembly and Assembly
108
4.2.4.6.2 Disassembling the ASF Rollers
1. Disassemble the ASF and remove the ASF rollers and hopper from
the ASF assembl
y
.
(
Refer to Section 4.2.4.6.
)
2. Take out the ri
g
ht and left compression sprin
g
s 1.66 from the back
of the hopper assembl
y
.
3. Separate the roller assemblies from the hopper.
4. Carefull
y
pull apart the roller frame and the roller cover.
Figure 4-17. Disassembling the Paper Feed Rollers
C om pression S pring 1.66
Roller
R oller Fram e
Roller Cover
