EPSON Stylus COLOR 440, 640, and 740 Chapter 6 Maintenance
145
Figure 6-5. Paper Feed and Paper Eject Rollers
Figure 6-6. Timing Belt Tensioning Mechanism
Figure 6-7. Hopper Assembly and ASF
No.6
No.7
Paper Feed R oller
Paper Eject R oller
No.8
Tensioning M echanism
No.9
No.10
H opper
ASF Fram e
