Epson Stylus Color 440 Service Manual

EPSON Stylus COLOR 440, 640, and 740 Chapter 6 Maintenance
144
Figure 6-3. Top Frame and ASF Drive Gear Figure 6-4. Gears
No.3
Top Fram e
(betw een arrow s)
No.11
G ear 34
No.5
No.4
No.4
No.4
G ear 23.2
G ear 16, 40.8
G ear 67.2
C om bination G ear
8, 14.4
