Pro 7900 and 9900 Field Repair Guide 10/6/10
Board (Main) Installation Printer Component, Software Item, LCD Display, Printer Button Page 29.
4. Plug in 10 Foil Cables that attach the Main Board to the Printer. Ensure that the Cables are
fully seated (straight).
Plug in 10 Foil Cables.
Note: The Foil Cables have their Connector Number printed on them.
